Beschreibung
-
Rahmen
Alloy Frame / Virtual 4 link kinematic VLK
27.5″ and 29″ compatible / geo adj. / Boost 148x12mm
140mm travel / Bosch Gen4 / Integr. removable Battery
Tapered Headtube E2, Central Kickstand Mount
Range Booster Ready -
Federweg
Front: 140mm / Rear: 140mm -
Gabel
Marzocchi Z2 Air / eMTB+
Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 140mm travel -
Dämpfer
X-Fusion NUDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 140-90-Lockout / 185x50mm
-
Lenker-fernbedienung
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 modes -
Antriebseinheit
Bosch Performance CX
EU: 25kmh / INT: 20mph -
Batterie
PowerTube 625Wh -
Display
Bosch Purion -
Ladegerät
4A Charger -
Schaltwerk
SRAM NX Eagle / 12 Speed -
Schalthebel
SRAM SX Eagle Single Click -
Kurbelsatz
FSA CK-320 / 165mm / 34T -
Kettenblatt
SRAM Eagle 34T DM / Steel -
Kette
SRAM SX Eagle -
Kassette
SRAM PG1210 / 11-50 T -
Bremsen
SRAM DB8 4 Piston Disc -
Bremsscheibe
Centerline CL Rotors 200mm F&R -
Lenker
Syncros Hixon 2.0 Rise / Alloy 6061D.B.
20mm rise / 8° / 740mm
Syncros Comfort lock-on grips -
Vorbau
Syncros FL2.0 / 6061 Alloy
L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8″ -
Sattelstütze
Syncros Duncan Dropper Post 2.5
31.6mm / S size 100mm / M size 125mm / L size 150mm -
Sattel
Syncros Capilano -
Steuersatz
Syncros ER2.0 Press Fit E2 / Tapered 1.5″-1 1/8″
OD 52/62mm / ID 44/56mm -
Vorderradnabe
Formula CL-811 / 15x110mm -
Hinterradnabe
Formula CL-148S / Boost 148x12mm -
Speichen
Stainless Black -
Felgen
Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready -
Vorderreifen
Maxxis Rekon / 29×2.6″ / 60TPI Wire Bead
EXO
Dual -
Hinterreifen
Maxxis Rekon / 29×2.6″ / 60TPI Wire Bead
EXO
Dual -
Beleuchtung
Bosch Light Cable pre-installed F&R -
Gewicht in Kg (ca.)
23.8 (with tubes)
