Beschreibung
-
Rahmen
Spark Carbon HMF
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline -
Gabel
FOX 34 Float Performance Elite Air FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle
44mm offset / tapered steerer / Reb. Adj. / Lockout
130mm travel -
Dämpfer
FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 120-80-Lockout / T165X45mm -
Lenker-fernbedienung
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
-
Schaltwerk
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed -
Schalthebel
Shimano XT SL-M8100-IR / Rapidfire Plus
Ispec EV clamp -
Kurbelsatz
Shimano XT FC-M8120-1 / Hollowtech 2
32T -
Innenlager
Shimano SM-BB71-41A / shell 41x92mm -
Kette
Shimano SLX CN-M7100 -
Kassette
Shimano XT CS-M8100-12 / 10-51 T -
Bremsen
Shimano XT M8120 4 Piston Disc -
Bremsscheibe
Shimano SM-RT76 / 6 Bolt / F&R 180mm -
Lenker
Syncros Fraser iC SL DC Carbon
0° rise / back sweep 8° / mini Rise / 760mm
Syncros Performance XC lock-on grips -
Sattelstütze
FOX Transfer Performance Elite Dropper Post
31.6mm / S size 125mm / M size 140mm / L size 150mm / XL size 150mm -
Sattel
Syncros Tofino 1.5 Regular
Titanium rails -
Steuersatz
Syncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB -
Laufradsatz
Syncros Silverton 2.0-30 6 Bolt
F: 15x110mm, R: 12x148mm
30mm Tubeless ready rim 28H / Micro Spline
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools -
Vorderreifen
Schwalbe Wicked Will 29×2.4″ EVO
Super Race / TLE / 67EPI / Addix Speed Soft -
Hinterreifen
Schwalbe Wicked Will 29×2.4″ EVO
Super Race / TLE / 67EPI / Addix Speed Grip -
Extras
Syncros Fork Fender -
Gewicht in Kg (ca.)
12.3 (Tubeless setup)
Hinweis: Fahrradspezifikationen können ohne vorherige Ankündigung geändert werden.
